• Analog FM
• NXDN, dPMR conventional
• Upgradable to NXDN Type-D trunking
• Upgradable to dPMR Mode 3 trunking*

* Not available in all regions.

• UHF 400-470 MHz / 450-520MHz
• 512 CH / 128 Zones
• 14 character dot-matrix display with status icons
• Improved user interface
• Programmable functions and menu items in a language other than English (For example French, Spanish, German, Russian and Turkish)
• Backlit LCD and buttons
• Continuous rotary knob and ON/OFF volume knob
• 1300mW loud and intelligible internal speaker audio
• MIL-STD-810 G shock, vibration, temperature and more
• IP67/66/55/54 waterproof & dust-tight protection
• 29 mm (1.1 inch) slim dimensions (with BP-290 battery pack)
• Intelligent battery information
• License key upgrade (trunking)

• NXDN or dPMR mode 1/2 conventional
• NXDN or dPMR multi-site conventional over IP network
• NXDN type-D single/multi-site trunking  (License key, ISL-UGMTR required)
• dPMR mode 3 trunking  (License key, ISL-UGMD3 required. Not available in all regions.)
• 12.5 kHz digital mode (NXDN conventional)
• Analog mode
• Analog/Digital mixed operation

• AMBE+2 vocoder
• Over-the-Air Programming (OTAP) function  (OTAP manager,  CS-OTPM1 required)
• Over-the-Air Alias (OAA) sends own name with a call
• Over-the-Air Update (OTAU) changes the repeater channel data and site code over the air (NXDN type-D trunking)
• Direct mode communication
• Individual, group and all call
• Late entry for group call
• Status call and polling
• Short data messages
• Call alert (NXDN)
• Transparent data mode

• CTCSS and DTCS tone
• 2-Tone and 5-Tone
• MDC functions (Depending on version)
• BIIS 1200 (MSK)
• LTR„¢ trunking (Depending on version)
• DTMF autodial

• Digital voice scrambler (Low level encryption)
• Analog voice scrambler (Inversion)
• Power ON password
• Tactical group temporarily reconfigures user talk groups
• Radio stun/revive/kill
• Remote monitor (NXDN)/Ambience listening (dPMR)
• Emergency key for emergency call
• Man down function
• Lone worker function
• Motion/stationary detection

• Priority scan
• Voting scan for site roaming

• Voice announcement (Channel number and zone)
• VOX function for hands-free operation
• Voice recording/playback (Up to 8 minutes)
• TX/RX active noise canceller
• TX/RX audio equalizer
• Audio compander (Analogue mode)

• Programmable vibration alert
• Built-in Bluetooth® for wireless audio and data
• Variety of optional audio accessories including speaker-microphones, headsets and earphones
• 14-pin accessory connector
• Wireless radio programming over Bluetooth®

## Supplied with Battery and Belt Clip Only - Chargers and Specific Frequency Band Antennas Ordered Separately ##

Available in 2 Variations:

IC-F62D-L  (400-470MHz)

IC-F62D-H  (450-520MHz)

## Please Specify Model Required When Ordering ##
